CPCCLDG3001 20 items
3D ViewerFlexible Steel Wire Rope (FSWR)
6×19 construction, core types (FC vs IWRC), WLL formula D²×9.6, temperature limits, rejection criteria
3D ViewerChain Slings — Grade 80 & 100
Switchable 60°/90°/120° models, WLL=D²×32, angle factors, shortening clutch, rejection criteria
3D ViewerDee Shackle
Pin types (screw vs safety bolt), WLL table 1t–12t, dee vs bow comparison, side-loading danger
3D ViewerEye Bolts — Collared & Uncollared
Angular load reduction (0°–45°), collared vs uncollared critical rule, installation requirements
3D ViewerSafety Hook
Latch function, tip loading danger, throat stretch test (5% rule), eye/clevis/swivel types
3D ViewerSpreader Bar
Eliminates sling angles, spreader vs lifting beam comparison, compression loading, selection criteria
3D ViewerRound Slings (Endless)
Colour coding by WLL (Purple 1t → Orange 10t+), polyester core, UV/chemical limits, hitch factors
3D ViewerBrick Cage
Material handling, fork pockets, loading procedure, exclusion zone rules, gate safety
3D ViewerSafety Cage (Personnel Platform)
Last resort use, harness required, trial lift procedure, 500kg WLL, AS 1418.17
3D ViewerEdge Lift Clamp
Tilt-up construction, cam jaw mechanism, self-locking under load, panel thickness matching
3D ViewerChain Block (Manual Hoist)
Weston brake mechanism, mechanical advantage 20:1–80:1, short-link chain, WLL 0.5t–20t
3D ViewerTwo-Way Radio
Crane communication protocol, PTT procedure, emergency commands, when radio vs hand signals
3D ViewerPlate Clamps (H & V)
Horizontal vs vertical types, animated cam mechanism, steel plate lifting procedures
3D ViewerBow Shackle (Anchor Shackle)
6.5t model, bow vs dee comparison, multi-leg sling use, pin rules, WLL table 1t–25t
3D ViewerFlat Webbing Slings
Switchable basket/choker models, colour coding by WLL, polyester vs nylon, edge protection
3D ViewerSynthetic Slings — Polyester & Nylon
Green 2t model, material comparison, colour coding, UV/chemical limits, edge protection rules
3D ViewerChain Links — Grade 80 vs 100
Switchable G80/G100 models, WLL formulas (D²×32 vs D²×40), identification markings, exam topic
3D CalcPipe Sling — Calculation Scenario
Reeved slings on pipes, weight formula, angle factors, worked exam question with step-by-step
3D CalcTimber Pole — Calculation Scenario
Timber density table, cylinder volume formula, reeved sling factor, wet vs dry timber warning
